Samsung Air Compressor Cooler
Samsung Compressor Cooler SM6100
Part Number List
#1 intercooler -part number HP16-002732C
#2 intercooler -part number HP16-002733C
#3 aftercooler -part number HP16-002734C
#1 intercooler -HP16-002732A HP16-002245A
#2 intercooler -HP16-002733A HP16-002246A
#3 aftercooler -HP16-002734A HP16-002247A
Samsung Hanwha Compressor Cooler SM6100 Overview
The Samsung Compressor Cooler SM6100 belongs to the Hanwha Power Systems SM100 Series. It is used for high-flow centrifugal compressor applications where cooler accessibility, water-side cleaning, pressure drop control and package reliability are important. Because these compressors may also be searched under Samsung, Samsung Techwin, Hanwha Techwin and Hanwha Power Systems names, this page uses Samsung / Hanwha SM6100 wording for legacy and current replacement cooler searches.
15,000 - 24,500 m³/hr
High-flow SM100 Series range for SM6100 cooler replacement.
3.5 - 13 Bar A
Pressure range for SM100 Series centrifugal compressor systems.
800 - 2,500 kW
Power band to check when reviewing heat load and cooling water duty.
Package type
Standard or package configuration affects cooler envelope and access.
SM100 Series focus
01
High-capacity users
Performance-centered SM100 Series design for demanding plant air service.
02
Plug-and-run package
Packaged configuration supports easier installation planning.
03
Type selection
Standard or package type depends on site layout and options.
04
Cooler replacement
Suitable for Samsung / Hanwha SM6100 cooler replacement and retrofit projects.
Industries & Applications
The SM100 Series is used across process air, instrument air, booster air and refrigeration-related compressor services. For cooler replacement, these applications are important because air flow, water quality, discharge pressure and duty cycle directly affect cooler sizing and material selection.
Upstream & Offshore
- Flash gas, LP, MP
- Vapor recovery / instrument air
Refinery
- Make-up, recycle, booster (H2, wet)
- Sulfur recovery / process air / instrument air
LNG
- Boil off gas (terminal, LNG plant)
- High pressure (terminal)
- Low / high duty (LNGC, LNG FPSO)
Power Generation
- Fuel gas booster / N2 booster (IGCC)
- Syngas / instrument air
Air Separation
- Main air / booster air or N2
- Cryogenic expansion
Fertilizer / Gas Processing
- Process air / process gas (NG, NH3, CO2)
- N2 booster / instrument air / NGL
Petro-chemical
- High pressure (terminal)
- Refrigeration (propane, propylene)
- PTA / boil off gas / process air / instrument air
Environment & Energy Saving
- Aeration for wastewater treatment
- Pneumatic conveying materials
- Mechanical vapor recompression
Cooler Related Design Highlights
Durable coolers
Water-in-tube bundles
Intercooler and aftercooler bundles allow simple maintenance and cleaning.
Corrosion resistance
Material selection helps protect compressor components in cooling water service.
Low pressure drop
Optimized airflow helps reduce loss across the cooler section.
Maintenance and package access
Simple service structure
Reduces maintenance effort and cost for SM6100 cooler work.
Lubrication reliability
Leak-free lubrication system supports gearbox and cooler service areas.
Package options
Base frame, cooling water manifold and enclosure can match package requirements.
SM6100 Specifications
| Model | SM3100 | SM4100 | SM5100 | SM6100 | SM7100 | |
|---|---|---|---|---|---|---|
| Flow Rate | m³/hr | 3,300 - 5,500 | 5,500 - 9,000 | 9,000 - 15,000 | 15,000 - 24,500 | 24,500 - 32,000 |
| CFM | 1,950 - 3,250 | 3,250 - 5,300 | 5,300 - 8,850 | 8,850 - 14,400 | 14,400 - 18,800 | |
| Power | kW | 200 - 580 | 300 - 930 | 500 - 1,500 | 800 - 2,500 | 1,000 - 3,100 |
| HP | 270 - 780 | 400 - 1,200 | 670 - 2,010 | 1,070 - 3,350 | 1,340 - 4,155 | |
| Discharge Pressure | Bar A | 3.5 - 13 | ||||
| Psi A | 50 - 188 | |||||
| Dimension (L×W×H) - Package type | mm | 5,250 x 2,250 x 2,500 | 5,500 x 2,250 x 2,500 | 6,250 x 2,250 x 2,550 | 7,100 x 2,250 x 2,550 | - |
| inch | 207 x 89 x 98 | 217 x 89 x 98 | 246 x 89 x 100 | 244 x 89 x 100 | - | |
| Dimension (L×W×H) - Standard type | mm | 3,210 x 2,150 x 1,920 | 3,800 x 2,300 x 2,050 | 4,750 x 2,490 x 2,130 | 5,290 x 2,400 x 2,420 | 5,700 x 2,800 x 2,950 |
| inch | 126 x 85 x 76 | 150 x 91 x 81 | 187 x 98 x 84 | 208 x 95 x 95 | 224 x 110 x 106 | |
| Weight | Kg - Package | 8,600 | 9,500 | 13,150 | 17,900 | - |
| Kg - Standard | 6,900 | 7,500 | 10,300 | 14,450 | 20,500 | |
* Dimension and weight are subject to change. P = Package type, S = Standard type.
Scope of Supply
Standard supply
- 01Air intake filter
- 02Inlet guide vanes
- 03Blow off valve and silencer
- 04Discharge check valve
- 05Complete lubrication system
- 06Aftercooler and drain ports
Package and options
- 07Main motor
- 08PLC control system
- 09Base frame and enclosure
- 10Cooling water manifold and optionsSound enclosure, dual oil filter and MODBUS / PROFIBUS interface can be selected when required.
For Samsung / Hanwha SM6100 cooler replacement, confirm whether the unit is package type or standard type, then check the cooler drawing, water-side conditions, compressor flow rate, discharge pressure and available maintenance space. Fete Vessel can support custom cooler replacement for Samsung Techwin legacy units and Hanwha Power Systems SM100 Series compressor service projects.
Share Article
| Brand Name: | Fete Vessel | Design Standard: | ASME, PED, CE |
|---|---|---|---|
| Place of Origin: | China | Condition: | New |
| Warranty: | 3 years | Production standard: | GB150.ASME.European standard. |
What are your strengths?
Ans. Our strengths lie in our expertise in design and manufacturing.
What is your estimated delivery time?
Ans. The delivery time varies depending on the specific product. Typically, it ranges from 10 to 40 working days.
What are your primary product offerings?
Ans. Our primary product offerings include industrial heat exchangers, pressure vessel, air dryer.
How can I get in touch with you?
Ans. We are available 24/7 through TradeManager for immediate assistance. Alternatively, you can contact us via email, WhatsApp, Skype, or WeChat. Select one of our products and message us, and we will promptly respond.
What are your payment terms?
Ans. Our payment terms require a 50% TT deposit in advance, with the remaining 50% TT balance due before delivery. We also offer the option of utilizing Alibaba Trade Assurance Service. We welcome any additional suggestions or inquiries regarding payment methods.
Feel free to Ask questions
Replacement support
Samsung Compressor Cooler SM6100 selection and replacement support
Fete Vessel supports engineers and purchasing teams who need a reliable replacement for Samsung Compressor Cooler SM6100. Share the compressor model, cooler dimensions, drawings, operating pressure, temperature, medium, and old part photos, and our team will compare the details before recommending a suitable manufacturing plan.
Fit and drawings
We review cooler dimensions, nozzle position, mounting size, drawings, old part photos, and site installation details.
Material and test
Each order can be checked for material, tube bundle layout, pressure test requirements, coating, packing, and delivery schedule.
Repair or replace
For urgent maintenance projects, we can help check whether an existing cooler can be repaired, retubed, or replaced.
