Sullair Compressor InterCooler

1. Product Overview: Core Thermal Management Unit for Multi-Stage Compression Systems

The Sullair Compressor InterCooler (hereinafter referred to as Sullair intercooler) is an interstage cooling device specifically designed for multi-stage compressed air systems. Its core function is to reduce heat accumulation during the compression process, ensuring system operational efficiency and equipment longevity.

Key Features:

• Modular design concept compatible with three mainstream structures: shell-and-tube, corrugated plate, and air-cooled types
• Example water-cooled model features 316L stainless steel cooling tube bundles with spiral baffle design
• Heat exchange efficiency exceeding 92% while maintaining corrosion resistance

2. Technical Specifications and Data-Driven Description

2.1 Structural Innovations and Material Applications

Type	Specifications	Performance Data
Shell-and-Tube Intercooler	Double-tube pass spiral wound structure	Total heat transfer coefficient reaches 850W/(m²·K) at 2.8m/s cooling water velocity
Corrugated Plate Intercooler	Herringbone corrugated plate stacking forming 3D turbulent channels	40% higher heat transfer efficiency than traditional flat plates with same heat exchange area
Air-Cooled Intercooler	Counterflow aerodynamic design with EC variable frequency fans	Maintains ≤15℃ temperature difference between outlet and inlet air at 40℃ ambient temperature

2.2 Performance Parameters and Control Logic

• Temperature Control Precision: Built-in PID temperature control module enables ±2℃ precise adjustment
• Pressure Adaptability: Stable operation within 0.8-3.5MPa pressure range through elastic sealing structure and pressure compensation valve combination design
• Energy Efficiency Optimization: Multi-stage variable flow control technology dynamically adjusts cooling medium flow according to load changes

3. Application Scenarios and Typical Cases

3.1 Industrial Gas Compression Field

Case 1: Natural gas pipeline booster station using Sullair shell-and-tube intercooler achieves 19% reduction in compression power consumption, saving over 2 million RMB annually in electricity costs.

3.2 Special Gas Processing Field

Case 3: Electronic specialty gas production workshop utilizes air-cooled intercooler with full fluorinated sealing rings and Hastelloy tube bundle design, achieving 10-year maintenance-free operation.

4. Maintenance Strategy

4.1 Preventive Maintenance System

Frequency	Maintenance Tasks
Daily Inspection	Check cooling medium level, monitor inlet/outlet pressure difference, record fan operating current
Monthly Maintenance	Endoscopic inspection of cooling tube walls, compressed air blowing of fins, safety valve calibration
Annual Overhaul	Disassembly cleaning, penetrant testing of tube sheets, replacement of all seals

5. Conclusion: Technological Evolution and Industry Value

Sullair Compressor InterCooler has redefined thermal management standards for compressed air systems through material innovation, structural optimization, and intelligent upgrades. Its modular design adapts to compressors ranging from 20kW to 2MW, covering wide temperature applications from -40℃ to 200℃.

In a global tender by a multinational chemical group, the product defeated several international brands with its 99.2% MTBF (Mean Time Between Failures) and 0.03% annual failure rate, verifying its technological leadership.
